• Most compact 10 Watt converter in DIP-16 metal casing
• Highest power density of 3.83 W/cm3
• 6-side shielded metal case with insulated base plate
• Wide 2:1 input voltage range
• High efficiency for low thermal loss
• Operating temperature range of -40°C to +85°C
• Built-in EN 55032 class A filter
• Current limitation and protection against short circuit
• 3 years product warranty

The TEL 10 series is a range of isolated 10 Watt DC/DC converters which come in a ultra
compact DIP-16 metal package. The design purpose of these series was to miniaturized
low power DC/DC converters to the maximum without sacrificing high efficiency. The TEL
10 series sets the new standart for power density with 3.83 W/cm3.
The TEL 10 series offers a wide 2:1 input voltage range and features a high efficiency of
up to 88% which enables an operation temperature of up to +70°C at full load and up to
85°C with 50% load.
The converters have an internal input filter to comply with conducted emission EN 55032
class A. The TEL 10 Series models feature an overall economical solution for space critical
and cost sensitive applications in instrumentation, IT and industrial electronics.
