The wide array of Virtex-4 FPGA hard-IP core blocks includes the PowerPC® processors (with a new APU interface),
tri-mode Ethernet MACs, 622 Mb/s to 6.5 Gb/s serial transceivers, dedicated DSP slices, high-speed clock management circuitry,
and source-synchronous interface blocks. The basic Virtex-4 FPGA building blocks are enhancements of those found in the popular
Virtex, Virtex-E, Virtex-II, Virtex-II Pro, and Virtex-II Pro X product families, so previous-generation designs are upward compatible.
Virtex-4 devices are produced on astate-of-the-art 90 nm copper process using 300 mm (12-inch) wafer technology

• XtremeDSP™ Slice
- 18 x 18, two’s complement, signed Multiplier
- Optional pipeline stages
- Built-in Accumulator (48-bit) and Adder/Subtracter

• Smart RAM Memory Hierarchy
- Distributed RAM
- Dual-port 18-Kbit RAM blocks
· Optional pipeline stages
· Optional programmable FIFO logic automatically remaps RAM signals as FIFO signals
- High-speed memory interface supports DDR and DDR-2 SDRAM, QDR-II, and RLDRAM-II.

• Cascadable embedded XtremeDSP slices with 18-bit x 18-bit dedicated multipliers, integrated Adder, and
48-bit accumulator.

• Digital Clock Manager (DCM) blocks provide self-calibrating, fully digital solutions for clock
distribution delay compensation, clock multiplication/division, and coarse-/fine-grained clock
phase shifting.
